Flat Track Ultra Thin Real Time GPS Tracker

The Blackline Flat Track™ features a large 5400 mAh battery, removal detection and an ultra-thin profile for REAL-TIME covert tracking and critical loss prevention applications.

Flat Track™ is the first ultra-thin covert tracker designed specifically to meet the needs of professional surveillance applications, delivering performance, durability and customization. Featuring a weather-sealed enclosure, Flat Track is prepared for duty out of the box and its thin profile allows flexible covert installation within a target’s vehicle. It is easily concealed under carpeting, behind paneling, and in compartments.

The Flat Track removal detection and alerting system is an industry first. This user-enabled feature indicates when Flat Track has been compromised on a target vehicle. A large 5400 mAh internal rechargeable Li-ion battery powers Flat Track. Coupled with user-configured schedules and monitoring options, Flat Track provides the tools to balance system responsiveness with battery life, ranging from two weeks to over two months between charges.

The Blackline Business Portal is an easy-to-use online interface that hosts Blackline business solutions, including Flat Track. The Business Portal enables mapping of real-time location, real-time continuous tracking, viewing past event data, schedule management and configuration of alert and notification settings.

Benefits:
• Self-contained tracking device designed to industrial performance standards.
• Increases awareness of a surveillance target’s activity.
• Removal detection & alerting indicates when Flat Track has been compromised.
• Quickly map a target vehicle location in the new Blackline Business Portal.
• Locate-on-motion automatically records target activity.
• Large capacity internal 5400 mAh battery extends surveillance life.
• Customizable scheduling provides user-controlled power management.
• Affordable surveillance
• Low training barrier
• Ultimate Sense® 2 high sensitivity GPS antenna makes the most of weak signal coverage.
• Easy-to-use web-based Blackline Business Portal for efficient mapping and administration.
• Quickly map previous routes with data from origin to destination.
• Firmware upgradable over-the-air accommodates future enhancements.
• Web-hosted user account. No software to install.

Specifications:

*Size & Weight
*Size: 182 mm W x 8 mm H x 240 mm L (7.2” x 0.3” x 9.5”)
*Weight: 181 g (6.4 oz)
*Buttons & Indicator Lights
*Button 1: Power on/off (with press of Button 2), indicator light wake-up
*Button 2: Battery level indicator wake-up
*Indicator light: Power, wireless connection status and battery level
*Wireless Communication
*Antenna: Internal quad-band
*Bidirectional communication
*Firmware upgrade over-the-air (FOTA)
*Assisted GPS
*Radio: 20-channel high sensitivity, mobile assisted
*Antenna: Internal Ultimate Sense® 2 GPS antenna extends operation in weak GPS signal conditions
*Accuracy: ~5 m (16 ft) outdoors, ~50 m (165 ft) indoors
*Real-time location turnaround time: ~20 seconds
*Mobile Messaging Methods
*Email, text message (SMS)
*Alert Messages
*Device removal detection, vehicle movement detection
*Notification Messages
*Low internal battery
*On-network (power-on and return-to-coverage)
*Off-network (power-off and out-of-coverage time-out)
*Scheduler
*Features include: Periodic automatic location, location-on-motion
*Scheduler intervals: Service plan dependent
*Power & Battery
*Rechargeable Li-ion battery: 5400 mAh Li-ion
*Environmental
*Storage temperature:-30 to 75°C (-22 to 167°F)
*Operating temperature: -20 to 55°C (-4 to 131°F)
*Ingress protection: IP65, 100% condensing humidity
*Approvals
*FCC Part 15 Subpart B, FCC ID: QIPBGS3, Industry Canada ICES-003, PTCRB type approval, RoHS
*Device Requirements
*Blackline GPS activated service plan
*GSM/GPRS Wireless communication coverage
*GPS Signal coverage required for GPS locating
*Warranty:
*1-Year limited factory warranty
*Activated Service Plans and Wireless Coverage
*Wireless coverage: Nearly 150 countries
*Blackline Business Portal Web Application
*Features Include: Event history, device location mapping, device management, alert & notification settings, and more

Blackline GPS Subscription Charges:

Activation: $29.95
1 Minute updates: $30.00 per month
10 second updates: $40.00 per month
